Scissor lift 5,0 T with lifting runways and auxiliary wheel-free lift
The GALAXIE551ELA is a 5T scissor lift with long runways (main lift) and under body lift (auxiliary lift).
Recessed in a pit, the flush mounted runways can accommodate vehicles with very low ground clearance.
This flushed mounted configuration saves space in the workshop.
Optional long drive-in ramps allow above ground installation (without the need of a pit), if required.
Options / Accessories
Auxiliary lifting
Standard lighting kit with 4 LED 24 bars
The GALAXIE551ELA is a 5T scissor lift with long runways (main lift) and under body lift (auxiliary lift).
Recessed in a pit, the flush mounted runways can accommodate vehicles with very low ground clearance.
This flushed mounted configuration saves space in the workshop.
Optional long drive-in ramps allow above ground installation (without the need of a pit), if required.
Size (in mm) :
Weight (en kg):
| TECHNICAL DATA | GALAXIE551ELA |
|---|---|
| Lifting capacity, main lift | 5,0 t |
| Lifting capacity, auxiliary lift | 3,5 t |
| Main runways, length | 5100 mm |
| Max. oil pressure – main lift | 250 bars |
| Alimentation pneumatique | 6 – 8 bars |
| Air supply | 400 V / 3 pH / 50 Hz / 16 A |
| Motor power | 2,2 kW |
| Net weight | 2358 kg |
| Certification | CE |
