Brake tester – 20T standard bibloc
This brake tester is used for heavy vehicle inspection and designed for intensive use. The weighing sensors are integrated on both chassis, allowing the weighing of the axle, wheel by wheel.
Options / Accessories
Single chain kit
Single layer
This brake tester is used for heavy vehicle inspection and designed for intensive use. The weighing sensors are integrated on both chassis, allowing the weighing of the axle, wheel by wheel.
Size (in mm) :
Parcel Nr.1 : 1200 x 1460 x 1350 mm
Parcel Nr. 2 : 1200 x 1460 x 1010 mm
Weight (en kg):
Parcel Nr.1 : 800 kg
Parcel Nr. 2 : 730 kg
| TECHNICAL DATA | 44700 |
|---|---|
| Axle load | 20 000 kg |
| Roller diameter | 250 mm |
| Minimum / Maximum clearance | 800 / 2 800 mm |
| Test speed | 2,2 km/h |
| Brake motors (exit help) | 2 x 11 kW |
| Maximum braking forces | 2 x 4 000 daN |
| Adhesion coefficient | dry > 0,7 / wet > 0,6 |
| Raised rear rollers | 35 mm |
| Clearance between frames | 580 mm |
| Two-speed management | optional |
