2- post lift overhead gantry lift 4,2 T
Our 2-post lift baseless AZUR42CH with a capacity of 4,2 T, providing a totally flat ground under the vehicle. This lift is particularly well adapted to electric vehicles.
Options / Accessories
Our 2-post lift baseless AZUR42CH with a capacity of 4,2 T, providing a totally flat ground under the vehicle. This lift is particularly well adapted to electric vehicles.
Size (in mm) :
Parcel Nr.1 : 2860 x 570 x 770 mm
Parcel Nr.2 : 1330 x 400 x 250 mm
Parcel Nr.3 : 850 x 250 x 350 mm
Parcel Nr.4 : 850 x 250 x 350 mm
Weight (en kg):
Parcel Nr.1 : 665 kg
Parcel Nr.2 : 66 kg
Parcel Nr.3 : 24 kg
Parcel Nr.4 : 10 kg
| TECHNICAL DATA | AZUR35CH |
|---|---|
| Link between columns | Baseless type |
| Main lift capacity | 4,2 t |
| Net weight | 730 kg |
| Max. lifting height | 1990 mm |
| Min. pad height | 90 mm |
| Lifting / lowering time | 40/55 sec. |
| Overall height | 3900 mm |
| Distance between columns | 2830 mm |
| Concrete slab min. thickness | 200 mm |
| Base plate for concrete slab thickness 130 mm | – |
| Front arms with 2 sliding parts, min./max length | 615-1150 mm |
| Rear arms with 1 sliding part, min./max. length | – |
| Front & rear arms (symmetrical), min./max length | – |
| Power supply | 400 V / 3 ph / 50 Hz / 20 A / 3,5 kW |
