LV axle play detectors – recessed
The LV play detectors trigger a mechanical stress to be applied on the wheels to check the various steering components and fluid leaks.
The plate movement is transversally controlled : longitudinal and diagonal movements are created by a wired remote control equipped with a LED lamp. The plates can be installed in a recessed manner in a concrete pit or placed directly on the ground (access ramps provided). They operate independently of each other.
Options / Accessories
The LV play detectors trigger a mechanical stress to be applied on the wheels to check the various steering components and fluid leaks.
The plate movement is transversally controlled : longitudinal and diagonal movements are created by a wired remote control equipped with a LED lamp. The plates can be installed in a recessed manner in a concrete pit or placed directly on the ground (access ramps provided). They operate independently of each other.
Size (in mm) :
Parcel Nr.1 : 1200 x 800 x 700 mm
Weight (en kg):
Parcel Nr.1 : 220 kg
| TECHNICAL DATA | 56100-A |
|---|---|
| Installation | Recessed |
| Axle load | 3 000 kg |
| Useful dimension per plate | 630 x 240 mm |
| Overall dimension | 720 x 550 x 165 mm |
| Plate transverse travel | 80 mm |
| Plate longitudinal travel | 80 mm |
| Thrust force | 1 060 daN |
| Operating pressure | 150 bars |
| Motor power | 2,2 kW |
